Rice Technician Control Panel — Production Ready
+92 322 4702943
SIMULATION MODE
Dashboard
Auto Operation View
Motors
M1 – M6 Control
Alarms
0 Active
Settings
Machine Connection
System Info
MachineRice Technician (Belsi)
Motors6 Units (M1–M6)
SOV ValvesAir + Water
Versionv3.0-prod
Connection
Protocol--
Gateway--
StatusChecking...
Last Data--
Safety
Emergency Stop Available
PIN Protected Settings
Alarm Monitoring
Audit Trail Active
Operation Mode
CURRENT:
AUTOMATIC
Auto Sequence Status
IdleMain Motor
Air Blower
Feed Shutter
SOV Valves
Motor Status Overview
Pressure
0.00
Flow Rate
0.00
E-STOP
Motor Control Panel
AutoIn AUTO mode, motors follow the startup sequence. Switch to MANUAL to control each motor individually.
Process Controls
Solenoid Valve Control
Solenoid valves for Air and Water control. Operate via Sensor (Auto) or Manual override.
Air SOV
Solenoid Valve — Air Supply
StatusOFF
Sensor0.0 PSI
Mode
Water SOV
Solenoid Valve — Water Supply
StatusOFF
Sensor0.0 L/min
Mode
Sensor Thresholds
45
15
Alarm Management
0 ActiveSystem Event Log
Machine Connection
Modbus Configuration
MQTT Configuration
Alarm Thresholds
Gateway Bridge Setup Guide
To connect to a real machine, you need a Gateway Bridge running on your local network next to the PLC/Controller:
# Architecture: [PLC/Controller] <--Modbus TCP--> [Gateway Bridge] <--HTTP API--> [This Dashboard] (Machine) (Port 502) (Your Server) (Cloud) (Cloudflare) # Gateway Bridge pushes state every 500ms: POST https://your-app.pages.dev/api/machine/state { "motors": { "M1": { "on": true, "fault": false, "amps": 12.5 }, ... }, "processes": { "FEEDING": { "on": true }, ... }, "sov": { "air": { "on": true, "sensor": 45.2 }, ... }, "pressure": 4.5, "flowRate": 18.3, "running": true, "mode": "auto", "_source": "gateway" } # Gateway Bridge polls for commands: GET https://your-app.pages.dev/api/machine/commands/pending [{ "id": 1, "command": "{\"action\":\"start\"}", "status": "pending" }] # Gateway acknowledges command execution: PUT https://your-app.pages.dev/api/machine/command/1 { "status": "acknowledged", "response": "OK" }
Supported PLCs: Siemens S7 (via Modbus TCP), Allen-Bradley (via Modbus TCP), Delta DVP, Schneider M340, any Modbus TCP/RTU compatible controller.
Arduino/ESP32: Use Modbus TCP slave library on ESP32 connected to relays/sensors. The gateway bridge reads Modbus registers and pushes to this API.
Operator
operator
Change Password
Change PIN
Your PIN is required to access Settings. Change it here.
Session
Logged in as operator
